ALL-TUBE PREAMP, IR TECHNOLOGY, COMPACT SIZE
The Friedman IR-J dual-channel tube preamp is an entire Friedman rig in a compact pedalboard-friendly package. IR-J boasts two fully independent foot-switchable channels based on Friedman’s legendary JEL-100 and JEL-20 designs which are rooted in Dave’s modded ‘800/PLEXI circuits. Powered by two high-voltage 12AX7 preamp tubes, each channel delivers deep harmonic richness and the touch response of a large format Friedman tube amp. The SYNERGY powered, state of the art, ultra-low latency, DSP IR cabinet/power amp simulation sends a studio-quality mic’d-up tone to your DAW or Front-of-House. The IR-J provides easy-to-use controls without complex menus and 100-page manuals.
- Jake E Lee Signature
- All-tube HIGH-VOLTAGE preamp – DI
- 2 x 12AX7 preamp tubes
- Two independent channels + TS style boost per channel
- Based on Friedman’s legendary JEL-100 and JEL-20 designs
- MIDI programmable features:
- Channel select / Boost
- IR select
- Thump, Presence and Low-Pass Filter – three-way switch per channel
- Effects loop ON/OFF
- Boost Lock
- Power amp simulation with software editable Presence, Thump and Low-Pass Filter (per channel)
- Low latency Impulse Response cabinet simulation (bypassable)
- Three position CAB/IR select switch per channel (programmable via software)
- 18 free Friedman IRs or load your own
- Boost Volume (top) – Vol. (gain amount) and Tone controls (per channel) on side panel
- Volume and Gain controls (per channel)
- Full EQ consisting of Bass, Middle, Treble (per channel)
- 3-way Bright switch (per channel)
- 2-way Gain switch (Channel 2)
- Three multi-function foot switches
- Ultra-transparent series FX loop (bypassable)
- TRS balanced output
- Headphone output
- MIDI 5 pin standard connector and USB MIDI
- USB software editor – powered by SYNERGY
- Limited 3-year Warranty
- Universal 12V Power Supply Included
- 6 Foot USB2.0 A Male to B Male cable Included
- Dimensions (Including Knobs): 5.5” (D) x 6.5” (W) x 2.3 (H)
- Weight: 1.5 lbs.
