SPECS
- neck type
- JBM5pc Maple/Walnut neck
- top/back/body
- Basswood body
- fretboard
- Bound Ebony fretboardJBM special inlay on 12th fret inlay
- fret
- Jumbo fretsPrestige fret edge treatment
- number of frets
- 27
- bridge
- Gibraltar Elite bridge
- string space
- 10.8mm
- neck pickup
- DiMarzio® Mirage™ (H) neck pickupPassive/Neodymium
- bridge pickup
- DiMarzio® Mirage™ (H) bridge pickupPassive/Ceramic
- factory tuning
- 1D,2A,3F,4C,5G,6C
- strings
- D'Addario® EXL117
- string gauge
- .011/.014/.019/.032/.044/.056
- nut
- Graph Tech® BLACK TUSQ XL® nut
- hardware color
- Satin Chrome & Satin Black
NECK DIMENSIONS
- Scale :
- 648mm/25.5"
- a : Width
- 43mm at NUT
- b : Width
- 58mm at 24F
- c : Thickness
- 18mm at 1F
- d : Thickness
- 20mm at 12F
- Radius :
- 430mmR
DESCRIPTION
SWITCHING SYSTEM
DESCRIPTION
CONTROLS
DESCRIPTION
OTHER FEATURES
- Gotoh® MG-T locking machine heads
- Luminlay side dots
- Deep and beveled lower horn scoop
- Hardshell case included
